Horse Power Required:                 200+ hp

Conveyor Motor:                             2000 series Charlyn 24 cube

Tank Capacity:                                2 x 500L Dip Tank

                                                           2 x 300L Liquid Fertilizer

                                                                2 x 60L Insecticide

Bin Capacity:                                  5T (Larger Capacity Upon Request)

Wheel Centre:                                 Standard 1630mm (Optional Spacers to go Wider)

Chute Width:                                  350mmm to 450mm

                                                               or 250mm to 350mmm (Adjustable)

Machine Dimensions:                   4600mm Long (Overall)

                                                               4250mm Wide (Overall)

                                                               2700mm High (Overall)

2500mm to Top of Bin at back

Dry Weight:                                    4.6T
